It can be tough when you're working outdoors all year round. You need the best equipment and the hardest working partners to get the job done. For those of you #DRIVENBYRESULTS - it's time to consider the Viking EPS and make your life a little easier while in the field.
Image Thumbnail

Functionality, durability and all-terrain ability.

The spacious 3-seat layout and walk-through floor ensure a comfortable and safe drive every time for you and your colleagues. Its double wishbone suspension is ready to take on the most rugged terrain - while the Euro-pallet sized tipping cargo bed can carry loads up to 272kg.

Equipped with our On-Command® drive system with 2WD, 4WD and 4WD with Diff Lock, and powered by a high-torque 686cc engine, the 3-seater Viking could be the best purchase you ever made!

At a glance

  • 3 seater utility ROV with walk through floor
  • Steel, pallet size tilting cargo bed for real load
  • Fully loaded with Yamaha Off Road technology
  • Sturdy, strong, straight forward utility ROV
  • Comfortable, spacious cabin with 3 bucket seats
  • Proven, torquey Yamaha 686cc single cylinder
  • T-category homologation optional

Viking EPS

When you work hard in a tough outdoors environment you need the best tools. So we've designed the Viking to make your job a bit easier - and more enjoyable.

Viking EPS Viking EPS
360° quick view

    Key Features

    Features Gallery
    Image Thumbnail
    • alt

      High-torque 686cc engine

      The high-torque 686cc single-cylinder engine produces plenty of controllable power for effective off road transportation. For added confidence on slippery downhill slopes the Ultramatic® transmission features an engine braking function - while the 2WD, 4WD and Diff Lock modes can be quickly selected to suit different surface conditions.

    • alt

      Electronic Power Steering (EPS)

      Even with 3 passengers and a full cargo load on board, the Electronic Power Steering (EPS) ensures that the steering feels light even when fully laden or when driving in heavy soils like clay. When 4WD with Diff-lock is selected the EPS switches automatically to a second program designed to optimize the steering characteristics.

    • alt

      Electronic Fuel Injection (EFI)

      The reliable 686cc 4-stroke single-cylinder engine features an advanced Electronic Fuel Injection system that ensures efficient combustion for good throttle response. Together with the forged piston and pent roof combustion chamber design, the EFI enables the Viking engine to produce gutsy torque at low rpm with strong high rpm performance.

    • alt

      3 mode On-Command® system

      The Viking is designed to be used on a wide variety of surfaces, and the 3-mode On-Command® system offers 2WD, 4WD or 4WD with Diff Lock options to suit different terrain and weather conditions. The simple rotary-type switch enables the driver to select their chosen drive mode in seconds.

    • alt

      Conveniently positioned controls

      For easy operation the Viking is equipped with a central instrument console, while the electric starter switch, shift lever and handbrake are located to the right of the 4-spoke steering wheel. And for added comfort and safety there's a foot space partition to prevent the central passenger's feet from interfering with the driver's feet.

    • alt

      Front and rear double wishbone suspension

      For responsive handling combined with a comfortable ride for all 3 people on board, the Viking is equipped with independent double wishbone suspension at the front and rear. This rugged system allows each wheel to follow the terrain and maintain traction on extremely rough ground, allowing you to traverse extreme landscapes.

    • alt

      3-seater / Walk-through floor

      The low noise cabin features an innovative 3-seat layout with a central seat inclined 5 degrees further back than the outer seats, giving each passenger more arm and shoulder room. There's also a flat walk-though floor that gives easy access and also allows the driver to step in from either side.

    • alt

      Easy maintenance

      The Viking has been designed to be robust and easy to maintain, and the location of the engine beneath the cargo bed makes it possible to gain access to the powerplant in seconds. Together with the easily accessible front-mounted components located under the hood lid, the Viking's design ensures that routine service times and costs are competitive.

    Technical Specifications

    Download Factsheet
    • Engine
      Engine type
      Single cylinder, 4-stroke, Liquid-cooled, SOHC, 4-valves
      Displacement
      686cc
      Bore x stroke
      102.0 mm x 84.0 mm
      Compression ratio
      10.0 : 1
      Lubrication system
      Wet sump
      Fuel system
      Electronic Fuel Injection
      Ignition system
      TCI
      Starter system
      Electric
      Transmission system
      Yamaha Ultramatic®, CVT, Centrifugal clutch
      Drive system
      On-Command® 2WD, 4WD, 4WD with Diff-lock
      Final transmission
      Shaft
    • Chassis
      Front suspension system
      Independent double wishbone, 205 mm wheel travel
      Rear suspension system
      Independent double wishbone, 205 mm wheel travel
      Front brake
      Dual hydraulic disc
      Rear brake
      Dual hydraulic disc
      Front tyres
      AT25x8-12NHS
      Rear tyres
      AT25x10-12NHS
    • Dimensions
      Overall length
      3,100 mm
      Overall width
      1,570 mm
      Overall height
      1,925 mm
      Wheelbase
      2,135 mm
      Min. turning radius
      4.5 m
      Minimum ground clearance
      300 mm
      Wet weight (including full oil and fuel tank)
      613 kgs
      Fuel tank capacity
      36.7 litres
      Oil tank capacity
      2.6 litres
      Seat height
      792 mm
    • Loading limits
      Cargo bed
      272 kg
    • Additional feature
      Steering System
      Ackermann-type with Dual Mode Electric Power Steering
